Victron Energy Cerbo GX MK2 & GX Touch 50 Bundle (BPP900450110 & BPP900455050)

Take complete control of your electrical system with the Victron Cerbo GX MK2 Bundle with GX Touch 50. Designed for campervans, motorhomes, caravans, boats and off-grid installations, this combination brings compatible Victron equipment together in one easy-to-monitor system.

The Cerbo GX MK2 acts as the communication centre of your installation, collecting live information from connected batteries, solar charge controllers, inverter/chargers and other supported equipment. The included Victron GX Touch 50 provides a clear 5-inch touchscreen for viewing system information and accessing controls from one convenient display.

Connect the Cerbo GX MK2 to the internet using Wi-Fi or Ethernet for access to the Victron Remote Management (VRM) portal. This enables remote Victron system monitoring, historical data, alarms and supported controls from a phone, tablet or computer.

Victron Cerbo GX MK2 Bundle for System Monitoring

Multiple VE.Direct, VE.Bus and VE.Can connections allow the Cerbo GX MK2 to communicate with a wide range of compatible Victron equipment, making it suitable for both straightforward leisure electrical installations and more advanced power-management systems.

Alongside the main communication connections, the Cerbo GX MK2 includes inputs for tank-level senders, temperature sensors and digital signals, plus two programmable relays. The included Victron GX display makes important system information easily accessible from inside your vehicle or boat.

What's Included

• Victron Cerbo GX MK2 – BPP900450110
• Victron GX Touch 50 – BPP900455050
• GX Touch mounting accessories
• 2m GX Touch connection cable

Key Features

• Central monitoring and control for compatible Victron equipment
• 5-inch colour touchscreen
• Live battery, solar, inverter and power-consumption information
• Remote monitoring through the Victron VRM portal
• Wi-Fi, Ethernet and Bluetooth connectivity
• Three isolated VE.Direct ports
• Two parallel VE.Bus connections
• Two VE.Can interfaces
• Four tank-level inputs
• Four temperature-sensor inputs
• Four digital inputs with pulse-counting support
• Two programmable relays
• Suitable for 12V, 24V and 48V leisure electrical systems

Technical Specifications

• Cerbo GX MK2 Supply Voltage: 8–70V DC
• VE.Direct Ports: 3
• VE.Bus Connections: 2 parallel RJ45 sockets
• VE.Can Connections: 2
• Network Connections: Wi-Fi and 10/100 Ethernet
• Tank-Level Inputs: 4
• Temperature Inputs: 4
• Digital Inputs: 4
• Programmable Relays: 2
• Cerbo GX MK2 Dimensions: 78 × 154 × 48mm
• Cerbo GX MK2 Protection Rating: IP20
• GX Touch Display: 5-inch touchscreen
• Display Resolution: 800 × 480 pixels
• GX Touch Dimensions: 87 × 128 × 12.4mm
• GX Touch Protection Rating: IP54 without connectors
• GX Touch Cable Length: 2m

For campervan, motorhome, marine and off-grid electrical systems, the Victron Cerbo GX MK2 Bundle provides a convenient way to bring system information and control together through the GX Touch display and Victron's remote monitoring platform.

Additional cables and sensors may be required to connect individual components. Remote VRM features require an internet connection.
